After delivering more than 50 GR Supra GT4 race cars to teams and with more than 50 class race wins in major Championships since its launch in 2020, Toyota Gaza Racing has now released details of the EVO version of the Supra, set for customer deliveries for the 2023 season.
Development engineers focused their efforts on three key areas: brakes, handling and engine.
With an improved brake system design, new ABS settings, updated KW damper technology and updated anti-roll bar specification, the GR Supra GT4 EVO will deliver improved handling and higher cornering speeds.
The EVO also boasts increased power and an optimised torque curve of the 3.0-litre, six-cylinder, turbocharged engine, which also benefits from more effective cooling.
The GR Supra GT4 EVO will make its competitive debut in January 2023 at the 24 Hours of Daytona, the first round of the IMSA Michelin Pilot Challenge season.
Orders for the GR Supra GT4 EVO will be taken from October 28 2022 and an upgrade kit will be available to existing GR Supra GT4 customers.
GR Supra GT4 EVO Technical Specifications
Chassis
- Length – 4,460mm
- Width – 1,855mm
- Construction – Steel/aluminium body with high-strength roll cage acc. to FIA regulations
- Front splitter – Natural fibre composite
- Rear wing – Natural fibre composite
- Fuel tank – ATL FT3 safety fuel cell with fast refuelling system (120litres)
- Driver’s seat – OMP racing seat with six-point safety harness (FIA 8862-2009)
Engine & Transmission
- Type – In-line six-cylinder, single twin-scroll turbocharger
- Displacement – 2,998 cm3
- Max. power – Depending on Balance of Performance (power sticks provided).
- Max. torque – Up to 660Nm＊
- Engine management – Marelli ECU
- Exhaust system – Akrapovic racing exhaust system with catalytic converter
- Lubricants – Ravenol
- Transmission – Modified ZF automatic transmission with paddle shift
- Differential – DREXLER Motorsport-specification limited-slip differential
- Driveshaft – GKN Motorsport high torque spec
Suspension, Steering, & Brakes
- Front suspension – MacPherson strut
- Rear suspension – Multilink
- Shock absorbers – KW adjustable racing dampers
- Steering – Rack and pinion, electrical supported
- Brakes (Front) – Brembo six-piston racing calipers, Steel ⌀ 390mm brake discs
- Brakes (Rear) – Brembo four-piston racing calipers Steel ⌀ 355mm brake discs
- Tires Front/Rear – Pirelli 305/660-18 Front / 305/660-18 Rear
- Wheels – OZ 11 x 18in
Electronic Control System
- Traction control – Standard
- ABS – Standard
- Digital display unit – Standard
- Data logger – Standard
- Rear view camera – Option
- Tyre pressure monitoring system – Option
- Suspension travel sensors – Option
Equipment
- Fire extinguishing system – Standard
- Air jack system – Standard
- Drinking system – Option
- Homologated endurance package – Option
＊ Depending on Balance of Performance
Sales price: A ready-to-race GR Supra GT4 EVO will be priced at 186,000 euros.
